16th April - Lancashire County Cricket Ground- Emirates Old Trafford, Talbot Road, Manchester

18th April - Reading Football Club, Reading, Berkshire, RG2 0FL

Anglia, partnering with Analog Devices are offering two in depth, technical workshops on signal conditioning.


The workshops will focus on the exploration of the signal chain and techniques to quantify noise. It will also include the examination of the signal conditioning of the analog /digital converters, along with bit resolution, speed, the reference voltage, optimization of resolution and filters.

Additionally, a technical dive into the Op Amp, including the structure and choice of components, influences, disruptive factors, suggestions for improving the signal chain, tools and circuit suggestions, along with practical tips.

For the hands-on session, an ADALM2000 Active Learning Module will be used (which will require all attendees to bring a laptop that requires installed driver for ADALM2000).

All attendees will take away an ADALM2000 Free of Charge!

The ADALM2000 works as a portable lab that, when used with a host PC, can augment classroom learning. Analog Devices’ Scopy software package supports the ADALM2000 and provides an intuitive graphical user interface (GUI) so users can learn faster, work smarter, and explore more. Built on open-source technology, Scopy can be examined and extended by anyone.
Scopy uses the features of the ADALM2000 to create,

• Voltmeters
• Digital oscilloscopes
• Spectrum analysers
• Power supplies
• Function generators
• Arbitrary waveform generators
• 2-port network analysers
• Digital logic analysers with bus analysers
• Digital pattern generators
• Digital static inputs/outputs

Agenda

• 09:00 Welcome
• 09:15 Theory Part 1: Op Amps
• 10:30 Coffee Break
• 10:45 Theory Part 2: ADCs
• 12:00 ADI Signal Chain Design & Analysis Tool
• 12:30 Lunch Break
• 13:30 Hands-On Workshop
• 15:30 Wrap-Up, Q&A

Theory Part 1: Op Amps - Demystifying noise

• Why do we care about noise
• What types of noise exist
• Noise in resistors, transistors, amplifiers
• How to compute the total noise
• How to estimate noise in amplifier circuits
• Comparison of theoretical analysis with simulations

Theory Part 2: A/D Convertors - Precision Signal Chain

• Introduction to Signal Chains
• Sampled Data Systems
• Introduction to Analog-to-Digital Converters ADCs
  • Type of ADCs
  • Driving ADC’s Inputs
• Driving ADC’s Reference
• Precision Signal Chain Analysis
• Signal Chain Noise Analysis
• Gain Stage considerations
• Digital Filtering Benefits

Hands-on Workshop: 0.1Hz to 10 Hz Demo
In the demo attendees are going to estimate the 0.1 Hz to 10 Hz noise for three different amplifiers from the datasheets:

• LT1782 – a low power op amp
• ADA4077 – a low noise op amp
• ADA4522 – a low noise, zero-drift op amp

The workshop will include,

Using the information provided to estimate the noise from the data sheet.
Use the ADALM2000 + demo board to measure the noise.
Compare our measured results to our estimated results.
Use the Network Analyzer feature of the ADALM2000 to measure the filter response from 1 Hz to 100 Hz.
Signal Chain Designer Demo and conclude with simulating the circuit on Signal Chain Designer and compare the results.

Presenter: Barry Mulligan

Job Title: Technical Marketing Manager - Analog Devices

Presenter Bio:
Barry Mulligan is a Technical Marketing Manager for the Interactive Engineering Solutions (IES) Group at Analog Devices, primarily focusing on leveraging ADIs SW design tools to create interactive experiences with more personalized engineering content on Analog.com. He has worked at ADI since 2016 in multiple roles including Digital marketing for the Industrial Automation BU, product marketing for Intelligent Buildings and Infrastructure BU, 5G transceiver applications engineer and supply chain planner for the RF product range at ADI. He also worked as a mechanical, electrical and plumbing engineer for design consultants Arup before joining ADI and spent a year working in Minnesota for Windlogics, a wind energy consultancy firm.

Presenter: Ivan Santos

Job Title: Product Applications Engineer - Analog Devices

Presenter Bio:
Ivan Santos works as a product applications engineer at Analog Devices in Limerick, Ireland, specifically in the Precision Converters Group. Before that, he was employed as a switch mode power supply design engineer serving the data center industry.

Presenter: Pierre Morris

Job Title: Field Applications Engineer - Anglia

Presenter Bio:
Pierre is a Field Application Engineer at Anglia Components Plc for Analog Devices. He graduated from Imperial College London with an MEng in Electrical and Electronic Engineering and has over a decade's experience as an electronics engineer.

Presenter: Will Mitchell

Job Title: Field Applications Engineer - Anglia

Presenter Bio:
Will is a Field Application Engineer at Anglia Components Plc for Analog Devices. Prior to distribution he was a hardware design engineer for BAE System's, working on safety-critical projects was involved with both the design and layout of analogue and digital solutions across multiple products. Now at Anglia, he covers a broad range of customers which include, but are not limited to, markets such as pro audio, augmented reality and comms.
