Murata reduces GIGAFIL RF filters' footprint by 72% for W-CDMA, LTE cellular basestations
The filters have been designed for cellular basestation applications which use a digital pre-distortion amplifier (DPD), as they feature a wide pass band and flat ripple performance, which are required for DPD PA design. The filter's small size (10.6 x 6.0 x 4.8mm) means they require 72% less mounting space compared to Murata's previous generation of filters for this application. The DFCL52G14LFHAB-TT1 is for use in W-CDMA Band1 DPD amplifiers, while the DFCL52G14LFHAA-TT1 will be used in W-CDMA Band1 LTE DPD amplifiers. The filters' highly sophisticated multi-pole design ensures high attenuation, and good selectivity. Both the two new members of the GIGAFIL series have a ripple of 0.4dB max. @ f0+/-30MHz and 1.2dB max. @ f0+/-65MHz, producing the wide and flat curves required at the pass band by DPD amplifier designs. For more information, or details on the full range of Murata products available from Anglia please call +44 (0)1945 474747 or email info@anglia.com
|
|
||||||||||||||||||||||||||||||||
|
This news article was originally published in January 2009.
7/1/09
