Miniature monitor saves portable battery life

Diodes Incorporated has announced a miniature current monitor delivering the world’s smallest solution size for battery current measurement in portable applications.

Packaged in the thin 4-pin 1.2mm x 1.8mm DFN package, the ZXCT1023 will support system management functions aimed at extending active run times.

A precision high-side current monitor, the ZXCT1023 has a fixed gain of 50 and needs just a single external current sense resistor for accurate current monitoring.  Consuming a typical quiescent current of just 3.5µA, the device will help reduce power drain and prolong battery life.

Its wide operating voltage range, from 2.5V through to 20V means the monitor will suit a broad range of Li-Ion and Li-polymer battery cell configurations.  Typical uses include battery charging, battery capacity measurement and over-current monitoring in applications including PDAs, mobile phones, and MP3 players.

For more information on the full range of Diodes Inc. products available from Anglia please call +44 (0)1945 474747 or email info@anglia.com

Alternatively, click on this link to go to the main Diodes Inc. section where you can view other news articles and product data.
