AVX expands Transguard® series to include miniature multilayer varistors

AVX Corporation offers designers the ability to clamp transients and filter EMI in one ultra compact device with the expansion of its Transguard® multilayer varistor series.

Designed for all small handheld devices, the miniature 0201 bi-directional transient voltage suppressor provides minimal signal distortion and low insertion loss.

“In addition to developing an advanced MLV that is miniature in size, the Transguard 0201 can decrease the chip count on printed circuit boards, reducing the amount of real estate needed,” said Sonja Brown, global product manager for circuit protection products at AVX. “The MLV is a cost-effective product that solves our customers increased need for a circuit protection device that meets space constraints and provides superior protection versus larger components.”

The Transguard 0201 multilayer varistors are ideal for handheld devices including mobile phones and PDAs, as well as embedded components such as hearing aids and camera modules.

Initial offerings of the miniature Transguard Series includes 15pf and 33pF capacitance devices with a 5.6V rating in an 0201 case size. These products have multiple strike capability and are able to withstand 1,000 strikes at 8KV of contact. The Transguard Series features a sub 1nS response time to ESD strike. The devices have a leakage current of <5uA at rated voltage.

Features
