Diodes expands portfolio of SBR products

Diode's portfolio expansion of SBR products

Diodes Incorporated has announced it has expanded its Super Barrier Rectifier (SBR) portfolio with the introduction of five new products packaged in DFN1006-2, SMA and ITO220S.

This new portfolio provides similar electrical performance as existing Schottky diodes whilst providing designers with additional performance benefits that include, lower high temperature reverse leakage, higher avalanche capabilities and thermal stability.

The SBR0240LP packages a 40V, 0.25A SBR in the tiny DFN1006-2 to address protection, voltage clamping and blocking circuit functions in end applications such as portable devices. The SBR20100CTP is the first Super Barrier Rectifier to be packaged in the isolated TO220 package.

Providing an isolation of 2kV, the SBR20100CTP delivers a low forward voltage drop of 0.82V at IF = 10A at 25°C, making it an ideal replacement for the Schottky diodes in the output stage of switched mode power supplies.

Click the following links to download a datasheet

For more information on the full range of Diodes Inc. products available from Anglia please call +44 (0)1945 474747 or email info@anglia.com

Alternatively, click on this link to go to the main Diodes Inc. section where you can view other news articles and product data.
