AVX's high-voltage SMD polymer tantalum capacitors reduce part count and provide design flexibility

THJ 200C

AVX Corporation has developed a surface mount polymer tantalum capacitor that is the first high-voltage device to feature a nominal capacitance rating of 10µF and rated voltage of 35V in the C case size (6.0x3.2x2.6mm), making it the smallest part of its type available.

Designated the TCJ Series, the capacitor delivers the industry's highest operating voltage (35V) for a tantalum capacitor with a conductive polymer cathode. The TCJ Series tantalum capacitors are also more stable than MLCC capacitors, which can also cause an audible noise due to piezoelectric effect.

The high operating voltage combined with the low profile design, reduces the part count and provides design flexibility in board layout, as well as aiding the design of thin products such as ultra slim monitors. The TCJ Series is ideal for applications such as, DC/DC converters supplying power for LCD TVs, base stations, rectifiers, switching hubs, routers and line filters, as well as LED power drivers in PC monitors, and LED TVs. The 35V TCJ capacitors also exhibit low ESR and require de-rating by only 20% (up to 85ºC), enabling them to be used at 28V for additional applications.

"Meeting the market's demand for maximizing power, performance and functionality while minimizing size and cost, AVX's reliable TCJ Series provides the industry's highest operating voltage in a small C case, while reducing the number of components needed on the PCB." said Dan Lane, marketing manager at AVX. "AVX's continued commitment to product development has enabled this break thru in surface mount conductive polymer cathode technology."

AVX's TCJ Series capacitors also feature a halogen-free, environmentally compliant design. Polymer tantalum capacitors offer several benefits including capability for higher power output circuits as they work at a higher line voltage and may also withstand higher ripple currents due to polymer tantalum low ESR technology. The cathode layer is made of a conductive polymer and there are no oxygen molecules, which can be easily released making capacitors more resistant to overloading and ignition enabling low voltage de-rating.

With an operating temperature range of -55ºC to +105ºC, the TCJ Series capacitors have undergone aging and screening processes to assure high reliability, achieving a low failure rate.

For more information, or details on the full range of AVX products available from Anglia, please call +44 (0)1945 474747 or email info@anglia.com
