Most power efficient drivers for 12-, 14- and 16-bit A/D converters unveiled
ADI's ADA4805 family of amplifiers featuring Dynamic Power Scaling provide best-in-class offset drift, slew rate, noise and distortion performance for portable, battery powered and high-density data acquisition equipment.
Analog Devices has introduced a family of low-power rail-to-rail amplifiers for high-speed data acquisition systems that require exceptional accuracy, precision and power efficiency. For system designers who are looking to achieve full datasheet specifications from high resolution A/D converters the ADA4805-1 (single) and ADA4805-2 (dual) amplifiers provide the only solution with quiescent current as low as 495µA.
The amplifiers Dynamic Power Scaling (DPS) feature allows users to dynamically manage the power consumption by shutting-down the amplifier between analog-to-digital converter samples. This further reduces by up to 90 percent the power consumption - with no performance degradation - when compared to similar solutions. Watch this video to learn more about the industry's most power efficient A/D converter drivers.
The 100-MHz ADA4805-1 and ADA4805-2 amplifiers achieve a high slew rate of 160 V/µs, low noise (5.9 nV/√Hz at 100 kHz) and low distortion (−102 dBc/−116 dBc HD2/HD3 at 100 kHz) while consuming only 1.5 mW of power. The amplifiers are designed for power-sensitive portable and battery-powered data acquisition devices, such as handheld or portable test and measurement instruments, battery-powered industrial equipment and remote environmental monitoring devices. They can also be used to reduce power and thermal dissipation in high-density applications such as cellular base stations and medical imaging equipment.
With exceptionally low offset-voltage drift of 1.5µV/°C maximum (0.2µV / 0°C typical), the ADA4805 family offers eight times lower drift performance than competing high-speed (100MHz) amplifiers. The combination of superior ac and dc performance allow designers to enhance system sensitivity, dynamic range and overall system accuracy.
The ADA4805-1/-2 amplifiers have a wide voltage range, supporting 3-V supplies, and in applications that require a wider dynamic range can also operate on supplies as high as +/-5V. The ADA4805 family efficiently drive a variety of A/D converters such as the AD7980 16-bit 1 MSPS; AD7091 ultra low-power 12-bit, 1 MSPS; AD7902 dual pseudo differential 16-bit 1 MSPS and AD7988 ultra low-power 16-bit SAR converters.
Click here for more information or buy from Anglia Live.
For more information, or details on the full range of Analog Devices products available from Anglia, please email info@anglia.com
